uFlamer X-Gasboom

Contact us for a quote

  • Product Description

      Introducing the innovative uFlamer® X-Gasboom, the first gas flamer that boasts 180° waving angles. Built upon the secure foundation of uFlamer Gasboom, it features advanced safety measures such as 0.1s super sensitive flame monitoring, cascadable power cut-off E-stop connector, and dual high voltage electron igniter. Plus, with its safety lock, dual magnetic valves, shut-off valve, and ARM warning light, you can rest assured of a worry-free experience. Choose from 5 optional nozzles and 2/4 built-in gas cartridge positions to achieve a varied flame effect height of 2 to 8m, perfect for indoor and outdoor events.

      Features and advantages:

      - The first gas flamer with 180° waving angles
      - Inheriting all the safety designs of uFlamer Gasboom
      - Super sensitive flame monitoring
      - Cascadable power cut-off E-stop connector, all flamers can be controlled with a single E-stopper box
      - Safety lock with switchable test mode, safer for service and testing
      - Dual high voltage electron igniter ensure successful ignition
      - Dual magnetic valves installed in series for double safety
      - 2 / 4 gas cartridges holder optional, support multiple gas cartridges
      - Individual shut-off valve, non-return valve and filter for each canister
      - Waterproof design, can be used in heavy rain
      - Different nozzles optional, 2-8m effects
      - Built-in 18650 battery design
      - Waving motor with angle block detection and memory function



      Specs:

      - Dimension: 400 x 360 x 350mm
      - Weight: 20kg
      - Input and Power: 100-240VAC, 50/60 Hz 200W
      - Housing Material: 304 stainless steel
      - Effect Direction: 180° (±90°)
      - Flame Height: 2-8m (nozzle size, firing time, temp. etc)
      - E-Stop Interface: Yes, can be connected in series
      - Dual Magnetic Valves: Yes, connect in series
      - High Sensitive Flame Monitoring: Yes, sensitivity up to 0.1s
      - Interface: NEUTRIK POWERCON TRUE1 IN/OUT;Waterproof 3-pin and 5-pin XLR IN/OUT
      - Control: DMX 512, 9-60V voltage input Wireless, with Wirelss DMX Receiver (5-PIN DMX IN with DC5V power supply)
      - Ignition: High Voltage Electron Ignition * 2
      - Built-in Battery Design: Yes, 8*18650 Lithium cells
      - Waterproof Level: Can be used in heavy rain
      - Firing Duration: 0.1-30s
      - Fuel: LPG propane or butane gas, gas cartridges bottle, aerosol cartridges
      - Cartridge Holder: Twin cartridge holder with 2 shut-off valves and 2 non-return valves;Quadruple cartridge holder with 4 shut-off valves and 4 non-return valves (optional)
      - Micro Filter: Yes, installed between shut-off and non-return valves
